A 100-dB SFDR 80-MSPS 14-Bit 0.35-$ muhbox m$BiCMOS Pipeline ADC

This paper describes a 14-bit 80-MSPS ADC with 100-dB SFDR at 70-MHz input frequency in a 0.35-mum single-well BiCMOS technology drawing 1.2 W from a dual 3.3 V/5.0 V supply. Key barriers to high dynamic range in pipeline ADCs at high clock rates and some methods to overcome these barriers will be presented. These methods include a sampling front-end without the use of a designated Sample and Hold (S/H). A BiCMOS switching input buffer is used along with the strategic use of BiCMOS design techniques. Also, calibration is combined with capacitor shuffling to maximize linearity with minimal noise impact

I. Introduction

The cellular infrastructure market requires high clock rate, high dynamic range analog-to-digital converters (ADCs) to enable efficient, advanced architecture receive channels. For cellular base stations and other communication systems, high-performance ADCs are key for receive channel throughput efficiency. High-speed, very high dynamic range ADCs can simplify system design, reduce overall cost, and maximize receiver sensitivity. Design of these ADCs presents difficult architectural tradeoffs. A great deal of research has been done in the industry and at the university level to understand these tradeoffs and find alternative design techniques. Although high-performance ADCs have been documented with other architectures (a sub-ranging ADC in a complementary bipolar process [1]), switched-capacitor pipelines have been a consistent choice for high clock rate, high dynamic range integrated ADCs. Some of the key tradeoffs and challenges in the design of high-speed, high-linearity switched-capacitor pipeline ADCs include: 1) amplifier limitations—the tradeoff among open-loop gain, headroom, and speed; 2) MOS switch charge injection; and 3) capacitor mismatch. These are summarized below and will be discussed more completely later in the paper.
